DESCRIPTION
timing belt is engineered for exceptional durability and precise synchronization in modern automotive engines. Utilizing advanced polymer compounds and reinforced construction, our timing belt ensures reliable power transmission between crankshaft and camshaft while maintaining exact valve timing.
STRUCTURE
1.Tensile Member——High Quality glass fiber with high tensile strength and elasticity that prevent belts from stretching.
2.Teeth Rubber——–strong thermotolerance and oil resistance, and super strong cohesion between core wire of tensile body and rubber teeth.
3.Teeth Fabric—– is protected by nyon 66 high-stretch cloth and is made strictly in accordance with technical specifications.
4.Top Rubber —–high-quality CR or HNBR which imported from Japan
Performance Specifications:
– Temperature range: -40°C to +150°C
– Tensile strength: 2500 N/cm
– OEM-compliant specifications
▸ Material Composition:
– 65% Hydrogenated Nitrile Rubber (HNBR) or CR
– 30% Aramid Fiber
– 5% Carbon Fiber Additives
ADVANTAGE
1.Improved performance: Timing belts help to synchronize the movement of the engine’s camshaft and crankshaft, ensuring precise engine performance. This synchronization leads to improved overall engine performance and efficiency.
2.Reduced noise and vibrations: Timing belts help to dampen noise and vibrations in the engine, leading to a smoother and quieter operation.
3.Durability: Timing belts are made of high-quality materials that are used for a long time in a working environment of 110°C and below ,stresses of the engine environment. This makes them more durable compared to other types of drive belts.
4.Reduced maintenance: Timing belts require less maintenance compared to timing chains or gears. They do not need to be lubricated and have a longer service life, reducing the need for frequent replacements.
5.Excellent resistance : good aging resistance (especially ozone resistance); good chemical stability: in addition to strong oxidizing acids, it is resistant to general chemicals; it is resistant to fire and water Good performance
SPECIFICATION
| Model | Pitch | Tooth height | Belt thickness |
| R(MR) | 9.525 | 3.5 | 5.5 |
| Y(MY) | 8 | 3.04 | 5.2 |
| ZBS | 9.525 | 2.8 | 5.1 |
| YU | 8 | 3.02 | 5.02 |
| RU | 9.525 | 3.44 | 5.4 |
| ZA | 9.525 | 1.91 | 4.1 |
| S8M | 8 | 2.95 | 5.2 |
| ZD | 9.525 | 3.5 | 5.5 |
| ZR | 9.525 | 3.2 | 5.4 |
| ZAS | 9.525 | 2.32 | 4.62 |
| RPP | 9.525 | 2.25 | 4.5 |
Vehicle Compatibility
| 080 ZA 19 | HONDA | 06141-611-305 |
| 084 ZA 19 | HONDA | 06141-634-305 |
| 087 ZA 19 | HONDA | 06141-642-305 |
| 094 ZA 19 | HONDA | 06141-657-305 |
| 095 ZA 19 | HONDA | 06141-657-306 |
| 092 ZA 19 | HONDA | 06141-673-305 |
| 087 ZA 19 | HONDA | 06141-679-305 |
| 087 MR 19 | HONDA | 06141-679-306 |
| 103 RU 24 | HONDA | 06141-P08-305 |
| 112 RU 24 | HONDA | 06141-P0A-305 |
| 155 YU 24 | HONDA | 06141-P13-305 |
| 127 RU 24 | HONDA | 06141-P14-305 |
| 101 RU 26 | HONDA | 06141-P1A305 |
| 104 RU 24 | HONDA | 06141-P28-305 |
| 103 RU 24 | HONDA | 06141-P2A-305 |
| 104 RU 24 | HONDA | 06141-P2E-301 |
| 124 RU 26 | HONDA | 06141-P2T-305 |
| 101 RU 26 | HONDA | 06141-P36-305 |
| 197 RU 24 | HONDA | 06141-P5A-305 |
| 126 RU 26 | HONDA | 06141-P72-305 |
| 097 ZA 19 | HONDA | 06141-PC0-305 |
| 108 MR 24 | HONDA | 06141-PC6-305 |
| 101 MR 24 | HONDA | 06141-PE3-305 |
| 129 MR 24 | HONDA | 06141-PG6-305 |
| 133 MR 24 | HONDA | 06141-PH3-305 |
| 192 RU 28 | HONDA | 06141-PH7-305 |
| 088 ZA 19 | HONDA | 06141-PH9-305 |
| 088 MR 19 | HONDA | 06141-PH9-306 |
| 098 RU 22 | HONDA | 06141-PJ7-305 |
| 107 MR 24 | HONDA | 06141-PK1-305 |
| 124 RU 24 | HONDA | 06141-PK2-305 |
| 106 RU 24 | HONDA | 06141-PM3-305 |
| 107 RU 24 | HONDA | 06141-PM6-305 |
| 124 RU 24 | HONDA | 06141-PM7-305 |
| 099 RU 26 | HONDA | 06141-PN4-305 |
| 124 RU 26 | HONDA | 06141-PR3-305 |
| 125 RU 26 | HONDA | 06141-PR4-305 |
| 241 RU 28 | HONDA | 06141-PR7-305 |
| 098 RU 24 | HONDA | 06141-PS4-305 |
| 113 RU 24 | HONDA | 06141-PT0-305 |
| 126 RU 24 | HONDA | 06141-PT2-305 |
| 113 RU 21 | HONDA | 06141-PV0-305 |
| 113 RU 21 | HONDA | 06141-PV1-305 |
| 196 RU 28 | HONDA | 06141-PY3-305 |
| 101 RU 26 | HONDA | 06141-PZ1-305 |
| 070 RU 16 | HONDA | 13405-PAA-A01 |
| 070 RU 16 | HONDA | 13405-PAA-A010-M1 |
| 070 RU 16 | HONDA | 13405-PAA-A02 |
| 070 RU 16 | HONDA | 13405-PAA-A10-M1 |
| 070 RU 16 | HONDA | 13405-PTO-004 |
| 087 ZA 19 | HONDA | 14400-371-014 |
| 087 ZA 19 | HONDA | 14400-371-305 |
| 080 ZA 19 | HONDA | 14400-611-004 |
| 080 ZA 19 | HONDA | 14400-611-014 |
| 080 ZA 19 | HONDA | 14400-611-024 |
| 080 ZA 19 | HONDA | 14400-611-040 |
| 084 ZA 19 | HONDA | 14400-634-003 |
| 084 ZA 19 | HONDA | 14400-634-004 |
| 084 ZA 19 | HONDA | 14400-634-005 |
| 084 ZA 19 | HONDA | 14400-634-014 |
| 084 ZA 19 | HONDA | 14400-634-015 |
| 084 ZA 19 | HONDA | 14400-634-050 |
| 087 ZA 19 | HONDA | 14400-642-004 |
| 087 ZA 19 | HONDA | 14400-642-305 |
| 095 ZA 19 | HONDA | 14400-653-024 |
| 094 ZA 19 | HONDA | 14400-657-000 |
| 094 ZA 19 | HONDA | 14400-657-004 |
| 094 ZA 19 | HONDA | 14400-657-014 |
| 095 ZA 19 | HONDA | 14400-657-024 |
| 092 ZA 19 | HONDA | 14400-673-004 |
| 087 ZA 19 | HONDA | 14400-679-000 |
| 087 ZA 19 | HONDA | 14400-679-003 |
| 087 ZA 19 | HONDA | 14400-679-004 |
| 087 MR 19 | HONDA | 14400-679-014 |
| 087 MR 19 | HONDA | 14400-679-024 |
| 087 MR 19 | HONDA | 14400-679-624 |
| 112 RU 24 | HONDA | 14400-P04-004 |
| 103 RU 24 | HONDA | 14400-P08-004 |
| 112 RU 24 | HONDA | 14400-P0A-004 |
| 192 RU 24 | HONDA | 14400-P0G-A01 |
| 155 YU 24 | HONDA | 14400-P13-004 |
| 127 RU 24 | HONDA | 14400-P14-004 |
| 101 RU 26 | HONDA | 14400-P1A-004 |
| 103 RU 24 | HONDA | 14400-P1G-E01 |
| 104 RU 24 | HONDA | 14400-P1H-E01 |
| 106 RU 24 | HONDA | 14400-P1J-E01 |
| 107 RU 24 | HONDA | 14400-P1K-E01 |
| 104 RU 24 | HONDA | 14400-P28-004 |
| 103 RU 24 | HONDA | 14400-P2A-004 |
| 104 RU 24 | HONDA | 14400-P2E-004 |
| 104 RU 24 | HONDA | 14400-P2F-A01 |
| 104 RU 24 | HONDA | 14400-P2FZ-A010-M1 |
| 124 RU 26 | HONDA | 14400-P2T-004 |
| 124 RU 26 | HONDA | 14400-P2TX-0040 |
| 113 RU 24 | HONDA | 14400-P45-G00 |
| 113 RU 24 | HONDA | 14400-P45-G01 |
| 197 RU 24 | HONDA | 14400-P5A-004 |
| 126 RU 26 | HONDA | 14400-P72-004 |
| 126 RU 26 | HONDA | 14400-P72-014 |
| 103 RU 22 | HONDA | 14400-P7A-004 |
| 125 RU 26 | HONDA | 14400-P7J-004 |
| 197 YU 26 | HONDA | 14400-P8A-A01 |
| 112 RU 24 | HONDA | 14400-PAA-A01 |
| 112 RU 24 | HONDA | 14400-PAA-A02 |
| 097 ZA 19 | HONDA | 14400-PC0-004 |
| 108 MR 24 | HONDA | 14400-PC6-004 |
| 108 MR 24 | HONDA | 14400-PD2-004 |
| 112 RU 24 | HONDA | 14400-PDA-E01 |
| 101 MR 24 | HONDA | 14400-PE0-004 |
| 101 MR 24 | HONDA | 14400-PE3-004 |
| 129 MR 24 | HONDA | 14400-PG6-004 |
| 129 MR 24 | HONDA | 14400-PG6-014 |
| 133 MR 24 | HONDA | 14400-PH3-004 |
| 192 RU 28 | HONDA | 14400-PH7-004 |
| 192 RU 28 | HONDA | 14400-PH7-014 |
| 088 ZA 19 | HONDA | 14400-PH9-004 |
| 088 MR 19 | HONDA | 14400-PH9-014 |
| 098 RU 22 | HONDA | 14400-PJ7-004 |
| 107 MR 24 | HONDA | 14400-PK1-004 |
| 124 RU 24 | HONDA | 14400-PK2-004 |
| 124 RU 24 | HONDA | 14400-PK3-004 |
| 104 RU 22 | HONDA | 14400-PLM-004 |
| 106 RU 24 | HONDA | 14400-PM3-004 |
| 107 RU 24 | HONDA | 14400-PM6-004 |
| 124 RU 24 | HONDA | 14400-PM7-004 |
| 099 RU 26 | HONDA | 14400-PN4-004 |
| 124 RU 26 | HONDA | 14400-PR3-004 |
| 125 RU 26 | HONDA | 14400-PR4-004 |
| 125 RU 26 | HONDA | 14400-PR4-A01 |
| 241 RU 28 | HONDA | 14400-PR7-004 |
| 241 RU 28 | HONDA | 14400-PR7-A01 |
| 098 RU 24 | HONDA | 14400-PS4-004 |
| 113 RU 24 | HONDA | 14400-PT0-004 |
| 126 RU 24 | HONDA | 14400-PT2-004 |
| 113 RU 21 | HONDA | 14400-PV0-004 |
| 113 RU 21 | HONDA | 14400-PV1-004 |
| 196 RU 28 | HONDA | 14400-PY3-004 |
| 101 RU 26 | HONDA | 14400-PZ1-004 |
| 088 MR 17 | HONDA | 14401-MN5-004 |
| 197 YU 26 | HONDA ACCORD | 14400-P8A-A010-M2 |
| 055 ZBS 13 | HYUNDAI | 23356-32010 |
| 055 ZBS 13 | HYUNDAI | 23356-32020 |
| 055 ZBS 13 | HYUNDAI | 23356-32030 |
| 055 ZBS 13 | HYUNDAI | 23356-32050 |
| 065 YU 13 | HYUNDAI | 23356-33140 |
| 065 YU 13 | HYUNDAI | 23356-33160 |
| 065 S8M 13 | HYUNDAI | 23356-38000 |
| 083 ZBS 19 | HYUNDAI | 23356-42010 |
| 083 ZBS 19 | HYUNDAI | 23356-42011 |
| 083 RU 19 | HYUNDAI | 23356-42200 |
| 099 YU 19 | HYUNDAI | 23356-42500 |
| 113 RU 25 | HYUNDAI | 23416-23201 |
| 100 YII 20 | HYUNDAI | 24312-02501 |
| 101 YII 20 | HYUNDAI | 24312-02701 |
| 092 ZA 19 | HYUNDAI | 24312-21040 |
| 092 RU 22 | HYUNDAI | 24312-22010 |
| 110 S8M 22 | HYUNDAI | 24312-22611 |
| 111 RU 25 | HYUNDAI | 24312-23001 |
| 113 RU 25 | HYUNDAI | 24312-23201 |
| 092 ZA 19 | HYUNDAI | 24312-24000 |
| 092 ZBS 19 | HYUNDAI | 24312-24010 |
| 092 ZBS 19 | HYUNDAI | 24312-24050 |
| 105 RU 22 | HYUNDAI | 24312-26000 |
| 122 RU 24 | HYUNDAI | 24312-32555 |
| 122 RU 19 | HYUNDAI | 24312-32560 |
| 123 ZBS 19 | HYUNDAI | 24312-32610 |
| 123 ZBS 19 | HYUNDAI | 24312-32620 |
| 123 RU 24 | HYUNDAI | 24312-32630 |
| 122 ZBS 19 | HYUNDAI | 24312-32820 |
| 122 ZBS 19 | HYUNDAI | 24312-32830 |
| 151 RII 29 | HYUNDAI | 24312-33010 |
| 151 RII 29 | HYUNDAI | 24312-33030 |
| 151 RII 29 | HYUNDAI | 24312-33040 |
| 151 RII 29 | HYUNDAI | 24312-33050 |
| 151 RII 29 | HYUNDAI | 24312-33060 |
| 153 RII 29 | HYUNDAI | 24312-33120 |
| 153 RII 29 | HYUNDAI | 24312-33130 |
| 122 RU 24 | HYUNDAI | 24312-33140 |
Quality Assurance
- Premature tooth shear
- material defects
- abnormal fiber separation
